Blue Sea 1450 DC 8 Position CLB Square [1450]

Description

DC 8 Position CLB Square

Features:

• High-density circuit protection
• Includes 4205-Square Format Label Set

Specifications:

• Positions: 8
• Nominal Voltage: 12V DC / 24V DC
• Maximum Amperage*: 90A
• Height: 4.75″ (120.65mm)
• Width: 4.88″ (123.95mm)
• Depth: 3.50″ (88.9mm)
• Weight: 1.25lb (0.57kg)

* Maximum amperage ratings are dependent on use of appropriately sized fuses and wire for a given application.

Includes:
(8) – 7056 – Push Button Reset Only Quick Connect Circuit Breaker – 15 Amps
(1) – 4205 – Basic DC Label Kit – 30 Black Square Labels [LABEL]

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to .

Specifications:

• AC/DC: DC
• Box Dimensions: 5″H x 9″W x 9″L WT: 1.25 lbs
• UPC: 632085014506
